L293D Motor Shield – Dual H-Bridge DC & Stepper Motor Driver | 4.5V-25V Input
Tested With:
About This Item
L293D Motor Shield – Dual H-Bridge DC & Stepper Motor Driver | 4.5V-25V Input
The L293D Motor Shield is a high-performance H-Bridge motor driver module designed for controlling DC motors, stepper motors, solenoids, and inductive loads with ease. This compact yet powerful module is perfect for robot ...ics, automation, and embedded systems.
Key Features & Specifications:
✅ Operating Voltage: 4.5V – 25V DC
✅ Output Current: 600mA per channel (1.2A peak, non-repetitive)
✅ Dual H-Bridge: Controls two DC motors or one stepper motor
✅ Enable Function: Each motor channel has an independent enable pin
✅ Over-Temperature Protection: Prevents damage due to excessive heat
✅ High Noise Immunity: Logical "0" input voltage up to 1.5V
✅ Internal Clamp Diodes: Provides protection against voltage spikes
✅ Logic Level Compatibility: Works with DTL & TTL logic signals
✅ Switching Frequency: Suitable for applications up to 5kHz
Applications:
🔹 Robotics & Motor Control – Drive DC and stepper motors in robotic projects
🔹 Automation & IoT Systems – Integrate with Arduino, Raspberry Pi, ESP32, and microcontrollers
🔹 Relay & Solenoid Control – Efficiently handle inductive loads
🔹 DIY Electronics & Prototyping – Ideal for hobbyists and makers
Package Includes:
📦 1 x Mini L293D Motor Drive Shield Module Expansion Board
This L293D motor driver module is a reliable and cost-effective solution for controlling motors in DIY, industrial, and educational projects. Its compact size, built-in protection features, and dual H-Bridge design make it an excellent choice for motor control applications.
