2S 8.4V 2A Type-C Li-ion battery charger module

Advanced 2S 8.4V 2A Type-C Li-ion Charger for DIY Projects
Discover the power of efficient charging with our 2S 8.4V 2A Type-C Lithium Battery Charger Module. Designed for DIY enthusiasts and electronics hobbyists, this module is perfect for powering your 2-cell lithium-ion battery packs used in ro ...botics, power banks, and custom electronic devices. It features a universal Type-C input for easy connection and provides a stable 8.4V output, ensuring optimal performance and longevity for your 18650 and other compatible Li-ion cells.

Product Specifications
Cell Configuration: 2S (2-Cell Series)
Input Port: Type-C USB
Input Voltage Range: DC 3V - 6V (Recommended: 3.7V, 5V)
Max Input Current: 2A
Charging Voltage: 8.4V (Nominal)
Output Current: 0.56A (Typical)
Switching Frequency: Up to 1MHz
Protection Features: Battery Overvoltage Protection, Battery Low Voltage Protection, Short Battery Protection, Input Undervoltage Protection
Operating Temperature: -40°C to +85°C
Dimensions (L x W x H): 39mm x 18mm x 6.3mm
LED Indicator: CR (Charging), OK (Fully Charged / CV Mode)
